Viewsonic Smartboard IFP7560

• 75” interactive flat panel
• 20 point multi touch
• Dual expansion PC slots
• Built-in ARM Quad-core CPU with 16GB storage
• Native Resolution 3,840 x 2160

Descriptions

75" Display, 3840 x 2160 Resolution, 350 cd/m2 Brightness

Featuring 4K Ultra HD resolution and an immersive InGlass™ touchscreen, the ViewSonic® ViewBoard® IFP7560 smartboard delivers incredible collaborative capabilities for 21st century boardrooms and classrooms. The highly accurate InGlass touch screen provides an incredibly natural handwriting experience, and allows multiple users to simultaneously write or draw on the 75” screen with their fingers and styluses. With a built-in quad-core processor, as well as versatile connectivity options including multiple HDMI, VGA, RS232, RJ45, and USB ports, this display provides powerful computing for annotation and multimedia playback without the need for a PC. The optional slot-in PC offers additional computing power for intensive interactive applications. The IFP7560 features a VESA-compatible design and can be placed on a wall mount, or on an optional trolley cart for flexible installation in classrooms and corporate meeting rooms.

Key Features

ULTRA HD RESOLUTION

With four-times the resolution of Full HD, this Ultra HD 3840×2160 display delivers a breathtaking viewing experience with immersive images that are vibrant, clear, and as large as life.

137225
inglass touch technology 450w

INGLASS™ TOUCH TECHNOLOGY

A FlatFrog InGlass™ touchscreen delivers an ultra-smooth, natural handwriting experience whether you’re using fingers or pens. Multiple users can collaborate at the screen with different pen and color strokes.

BUILT-IN SECURITY

An integrated FIPS-201 certified, Windows Hello fingerprint reader allows for convenient and secure single sign-on to the ViewBoard display.

built in security 450w

OUT-OF-BOX COLLABORATION

Integrated with ViewSonic vBoard embedded software and ViewBoard® Cast, as well as Zoom® software, this display delivers out-of-the-box annotation and content sharing capabilities. This display can also be upgraded with Intel® Unite, which can wirelessly and securely display media from any range of devices such as tablets, laptops, and mobile phones.

INTEL UNITE ® CERTIFIED

ViewSonic ViewBoard IFP60-series and the optional VPC12-WPO-2 slot-in PC are certified by Intel Unite. Powered by Intel® vPro™ technology, the Intel Unite solution delivers a productive and secure unified communications platform for boardrooms and classrooms.

intel unite certified 450w 1
room filling sound ifp6560 450w

ROOM-FILLING SOUND

Designed with dual, front-facing speakers, this display provides clear, room-filling sound for an incredibly immersive viewing experience.

Specifications

DIMENSIONS (IMPERIAL) (WXHXD)

PACKAGING (IN.)

76.6 x 48.3 x 11.0

PHYSICAL (IN.)

70.5 x 43.1 x 4.3



DIMENSIONS (METRIC) (WXHXD)

PACKAGING (MM)

1945.0 x 1230.0 x 280.0

PHYSICAL (MM)

1789.5 x 1094.5 x 108.1

OS

Embedded ViewBoard OS



GPU

ARM Mali450 MP4



CPU

ARM Quad Core Cortex A53



CPU PROCESSOR SPEED

1.4GHz



MEMORY

2GB



STORAGE

16GB



BUILT-IN SOFTWARE

myViewBoard, Chromium browser, Zoom, ViewBoard Cast

DISPLAY

DISPLAY SIZE (IN.)

75

VIEWABLE AREA (IN.)

75

LIGHT SOURCE

LED

RESOLUTION

3840 x 2160

ASPECT RATIO

16:9

STATIC CONTRAST RATIO

4,000:1

BACKLIGHT LIFE (HOURS)

50,000

BRIGHTNESS

350 cd/m2

RESPONSE TIME (TYPICAL GTG)

8ms

VIEWING ANGLES

178º horizontal, 178º vertical

PANEL SURFACE

Anti-glare 7H tempered glass

OPERATION RATING

16/7

NETWORKING

ETHERNET LAN

10/100 Mbps

AUDIO

INTERNAL SPEAKERS

10W (x2)

CONNECTOR

HDMI 1.4 IN

1

HDMI 2.0 IN

2

HDMI OUT

1

VGA

1

DISPLAYPORT

1

3.5MM AUDIO IN

1

3.5MM AUDIO OUT

1

USB 3.0

2

USB 2.0

3

OPS PC SLOT

1

USB B TOUCH PORT

2

RS232

1

ETHERNET LAN (RJ45)

1

SDM SLOT

1

POWER

VOLTAGE

100-240 VAC

CONSUMPTION (TYPICAL)

397W

STAND-BY

<0.5W

CONTROLS

ON SCREEN DISPLAY

Input, Volume, Backlight, Audio, Screen, Display, Adjust

REMOTE CONTROL

Volume, Channel, Source, Mute, Back, Input, Menu

OPERATING CONDITIONS

TEMPERATURE

32-104º F (0 - 40º C)

HUMIDITY (NON-CONDENSING)

10-90%

TOUCH

TOUCH TECHNOLOGY

InGlass

TOUCH POINTS

20-Point Touch
WEIGHT (IMPERIAL)

NET (LBS)

136.7

GROSS (LBS)

177.0

WEIGHT (METRIC)

NET (KG)

62.0

GROSS (KG)

80.3

MOUNT

VESA COMPATIBLE

800 x 400 mm

GENERAL

WARRANTY

3-year limited warranty on parts, labor and backlight, onsite warranty

RECYCLE/DISPOSAL

Please dispose of in accordance with local, state or federal laws.

REGULATIONS

cTUVus, FCC, ENERGY STAR 7.0, Mexico Energy, CE, CB, RoHS, ErP, WEEE

IFP7560 Display, Stylus Pen x 2, Power Cable, Remote Control with Batteries, Quick Start Guide, Camera Plate, USB Cable, HDMI Cable
