SAMSUNG VHT-E Series

Videowall

Eye-catching bright and brilliant contents delivery with extreme narrow bezel video wall displays

An extreme narrow 1.8mm bezel-to-bezel design creates seamless visual experience
700 nit brightness and non-glare panel provide high visibility 24/7
Wide viewing angles enable clear image presentation for more viewers in large spaces
Picture enhancement technology delivers optimized visuals

Tag: Samsung

Description

Descriptions

video wall ultra narrow videowall lcd samsung vm55t u cover

Key Features

Always-on, space-saving solution with extreme-narrow bezels

See an immersive and dependable viewing experience, 24/7 with Samsung’s VHT-E series. The display’s slim depth and 700 nit brightness ensures highly visible images and legible messages in a wide range of locations from shopping malls to lobbies, meeting rooms, control rooms and more.

Transform any space with high impact visuals

The slender design and 70.4mm cabinet depth provide flexibility for installation and an extreme-narrow 1.8mm bezel-to-bezel width creates a seamless picture opening endless possibilities for designing a captivating visual experience.
extreme narrow bezel video wall displays samsung vht e series banner 1
* Exact depth varies by display size.

View content from any angle

Wide viewing angles mean content is easily visible even if viewers aren’t standing directly in front of the display. Audiences can get clear details and vivid colors regardless of where the screen is located.
video wall ultra narrow videowall lcd samsung vm55t u banner 3

Vibrant images in any light

Non-glare panels evenly distribute light across the screen to maintain vibrant and accurate content. Combined with a high contrast ratio and 24/7 operation, visuals are vivid and eye-catching any time of the day or night — regardless of ambient light.
extreme narrow bezel video wall displays samsung vht e series banner 3

Image enhancement

Samsung’s powerful picture enhancement technology ensures all content is vibrant and clear. With Picture Enhancer mode, color saturation and contrast are improved by adjusting the gamma curve. Using Black Equalizer mode, dark images are lightened, making details easier to see.
extreme narrow bezel video wall displays samsung vht e series banner 2

Comprehensive calibration to fit your needs

Multi-step factory tuning provides uniform brightness and color. Users can also fine-tune advanced settings with free powerful Color Expert Pro software. For quick and simple calibration, Color Expert Pro Mobile enables white balance adjustments for video wall displays up to 5×5 using a mobile camera.

extreme narrow bezel video wall displays samsung vht e series banner 5

Advanced presentation, simplified operation

Utilizing daisy chain design through DisplayPort 1.2 or HDMI ports enables the display to present UHD content on multiple screens without an external graphic card. Samsung’s UHD Signage Player Box streamlines functionality by combining the media player and content management software.
extreme narrow bezel video wall displays samsung vht e series banner 6

Industry standard certified

IP5x certified, the VHT-E series is dust-resistant and able to withstand a range of environmental conditions without needing to prepare additional enclosure. The display packaging also passed a rigorous 4-step test in an ISTA-certified laboratory designed minimizes possible damage during delivery.
extreme narrow bezel video wall displays samsung vht e series banner 7
video wall ultra narrow videowall lcd samsung vm55t u slide 5
video wall ultra narrow videowall lcd samsung vm55t u slide 4
video wall ultra narrow videowall lcd samsung vm55t u slide 3
video wall ultra narrow videowall lcd samsung vm55t u slide 2
video wall ultra narrow videowall lcd samsung vm55t u slide 1

Specifications

Diagonal Size 55"

Type IPS

Resolution 1920*1080 (Full HD)

Pixel Pitch(mm) 0.63mm(H)*0.63mm(V)

Active Display Area(mm) 1209.6 * 680.4 mm

Brightness(Typ.) 500 nit

Contrast Ratio 1200:1

Viewing Angle(H/V) 178/178

Response Time(G-to-G) 8ms

Display Colors 8 bit - 16.7M

Color Gamut 72%

Operation Hour 24/7

Haze 25%

Dynamic C/R 500,000:1

H-Scanning Frequency 57.3kHz ~ 70kHz

V-Scanning Frequency 48Hz ~ 75Hz

Maximum Pixel Frequency 78MHz



Input
RGB DVI-D, Display Port 1.2

Video HDMI 2.0 (2)

HDCP HDCP 2.2

Audio Stereo mini Jack

USB Only F/W upgrade



Output
RGB DP1.2(Loop-out)

Audio Stereo mini Jack

External Control RS232C(in/out), RJ45

External Sensor Detachable type(IR)

Type Internal

Power Supply AC 100 - 240 V, 50/60 Hz



Power Consumption

Max[W/h] 270

Typical[W/h] 116

BTU(Max) 921.0

Sleep mode less than 0.5W

Off mode less than 0.5W

Operating Temperature 0 ℃ ~ 40 ℃

Humidity 10 % ~ 80 %



Safety

UL (USA) : UL 60950-1 CSA (Canada) : CSA C22.2 No. 60950-1 TUV (Germany) : EN60950-1 NEMKO (Norway) : EN60950-1 KC (Korea) : K60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore) : IEC60950-1 GOST (Russia) : IEC60950-1, EN55022 SIQ (Slovenia) : IEC60950-1, EN55022 PCBC (Poland) : IEC60590-1, EN55022 NOM (Mexico) : NOM-019-SCFI-1993 IRAM (Argentina) :IEC60950-1 SASO (Saudi Arabia) : IEC60950-1

EMC

FCC (USA) FCC Part 15, Subpart B class A CE (Europe) EN55022, EN55024 VCCI (Japan) VCCI CISPR32:2016 KCC (Korea) :KN32, KN35 BSMI (Taiwan) : CNS13438 (CISPR22) C-Tick (Australia) : AS/NZS CISPR32:2015 CCC(China) :GB9254-2008, GB17625.1-2012

IP Rating IP5X

Media Player Signage player box

Key Features Extreme Narrow Bezel

Orientation N/A

Remote Control N/A

Special Features ACM Support(Advanced Color Management), Auto Source Switching & Recovery, Haze 28%, Temperature Sensor, RS232C/RJ45 MDC, Plug and Play (DDC2B), Video Wall(15x15(OSD)), Video Wall Daisy Chain(10x10), Pivot Display, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain(Supporting UHD Resolution, HDCP support), Smart F/W update, Clock Battery(168hrs Clock Keeping) IP5X tested, EMC Class A

Dimension (mm)

Set 1211.5 x 682.3 x 70

Package 1398 x 844 x 257

Weight (kg)

Set 19.4kg

Package 27.6kg

VESA Mount (mm) 600 * 400 (mm)

Bezel Width (mm) 0.9mm (Even)

Included

Quick Setup Guide, Warranty Card, DP cable, stereo to DB9 cable, Power Cord, Remote Controller, Batteries, External IR

Optional

Stand
N/A

Mount
WMN-55VD

Specialty
N/A
