Main control chip

 High-performance AI SoC (4-core A7 + NPU + DSP)

RAM

1GB DDR3 high-performance memory

Memory

8GB high-speed eMMC onboard

Recognize height

1.2 ~ 2.2 meters, adjustable angle

Recognition distance

0.5 ~ 2 meters, depending on the lens

Face angle

30 degrees left and right, 30 degrees up and down

Alarm input

2 alarm inputs

Alarm Output

1 alarm output

power supply

DC 12V

Network Interface

1 RJ45 10M / 100M adaptive Ethernet port

1 2.4G wifi module

USB interface

1 USB 2.0 interface

Wiegand interface

1 Wiegand interface
